Hyundai Santa Fe (DM): Components and Components Location - Power Door Locks - Body Electrical SystemHyundai Santa Fe (DM): Components and Components Location

Component Location

1. Driver power window main switch
2. Passenger window switch
3. IPM (Intalligent intergrated Platform Module)
4. Door lock switch
5. Tailgate lock actuator & switch
6. Front door lock actuator & switch
7. Rear door lock actuator & switch


Power Door Lock Actuators. Repair procedures
